What VPS Terminal is

VPS Terminal lets your customers connect to their VPS (Virtual Private Server) through a secure, browser-based SSH terminal inside the whitelabel customer portal. No SSH client installation or key management is required on the customer’s end — everything runs in the browser using xterm.js. Key security properties:
  • Private SSH keys are encrypted with AES-256-GCM and stored in PostgreSQL — they are never sent to the browser
  • Connections use WebSocket-based tunnels via a dedicated server
  • Session tokens are single-use and expire after 30 seconds
  • Each session requires a fresh token request, preventing replay attacks

​
How partners enable it

VPS Terminal must be enabled at two levels before customers can use it.

​
Step 1 — Partner-level feature flag

The feature is controlled by the ENABLE_VPS_TERMINAL / NEXT_PUBLIC_ENABLE_VPS_TERMINAL environment variables on the platform side. Contact Knotie AI support to enable this flag for your partner account if it is not already active.

​
Step 2 — Customer-level toggle

Once the platform flag is enabled:
  1. Open Customers.
  2. Select the customer.
  3. Open Manage.
  4. Go to Features & Add-ons.
  5. Find VPS Terminal and toggle it on.
The toggle only appears if the platform-level feature flag is active.

​
How customers access it

Once VPS Terminal is enabled for their account, customers find it inside their whitelabel portal:
  1. Log in to the customer portal.
  2. In the sidebar navigation, click Server Terminal (under the customer tools section).
  3. If no VPS credentials are on file yet, they are prompted to add them before connecting.
[SCREENSHOT: VPS Terminal in whitelabel sidebar]

​
Prerequisites (customer side)

Before connecting, the customer needs to have their VPS credentials stored in the portal. This typically includes:
  • VPS hostname or IP address
  • SSH port (default: 22)
  • Username
  • SSH private key (uploaded and encrypted by the platform — never exposed to the browser)
If credentials are not yet configured, the VPS Terminal UI prompts the customer to add them before a connection can be established. [SCREENSHOT: VPS Terminal connect form]

​
How the connection works

  1. Customer clicks Connect in the VPS Terminal view.
  2. The platform generates a single-use session token (valid for 30 seconds).
  3. A WebSocket tunnel is established between the browser and the VPS via the Knotie AI proxy server.
  4. The xterm.js terminal in the browser communicates with the VPS over this tunnel.
  5. The session ends when the customer disconnects or the token expires.
Each connection requires a new session token. There is no persistent tunnel left open between sessions.

​
Security notes

  • SSH private keys are encrypted at rest using AES-256-GCM. The plaintext key is held only in the proxy server’s memory during an active session and is never transmitted to the browser or stored in plain text.
  • Session tokens are short-lived (30 seconds) and single-use.
  • Connections are tunneled through Knotie AI infrastructure — the VPS’s SSH port does not need to be publicly accessible if the proxy server can reach it.

​
Phase 2 — Connect Hub migration

In a future release, VPS Terminal connectivity will be migrated to the Connect Hub infrastructure, which will replace the current custom WebSocket proxy approach. This will not change the customer-facing experience.

​
Screenshots

[SCREENSHOT: VPS Terminal in whitelabel sidebar] [SCREENSHOT: VPS Terminal connect form]
